Charge Coordination with Blue Sea Systems Automatic Charging Relays (ACR) controls ACR state ensuring proper float stage for each battery
Battery Temperature Compensation - adjusts charge voltage based on battery temperature
AC over and under voltage shut down and automatic restart
Over and under battery temperature protection - charger will not operate if battery temperature rises above or falls below a set value
DC over voltage and reverse polarity protection
Surge and short circuit protection
Specifications:
Total Output Current: 25A
Input AC Current: 4.5A @ 100V AC / 2.25A @ 200V AC
Maximum Output Voltage: 16V DC
Nominal Voltage: 12V DC
Ignition Protected: Yes
Number of Outputs: 1 negative / 3 positive
Universal AC Input Voltage: 90-265V AC
AC Input Frequency: 45-65Hz
Output Voltage Accuracy: 0.05V
Typical Float Voltage: 13.5V DC
Minimum Operating Temperature: -20° C
Maximum Operating Temperature: 70° C
Minimum Storage Temperature: -30° C
Maximum Storage Temperature: 80° C
Battery Types: AGM / Flooded Lead Acid / Gel / TPPL (Thin Plate Pure Lead)
Recommended for Battery Bank Sizes: 330Ah Maximum / 60Ah Minimum
Warranty: 5 Year
Height: 13.03" (330.96 mm)
Width: 8.46" (214.88 mm)
Depth: 3.66" (92.96 mm)
Weight: 13.00lb (5.9 kg)
